Industrial Water Softening System with Deionization | High Purity Water Purification
Product Overview
Adaptable to various inlet water quality conditions, the system supports customizable capacities ranging from 0.5m³/h to 80m³/h. It can be configured with automatic control valves, heavy-duty filter tanks and premium ion exchange resins to perfectly match your specific water treatment requirements.
| Item | Specification |
|---|---|
| Product Name | Industrial Water Softening System with Deionization |
| Treatment Capacity | Customizable from 0.5 m³/h to 80 m³/h |
| Inlet Water Hardness | ≤ 8 mmol/L (higher hardness available with pre-treatment) |
| Effluent Water Hardness | ＜ 0.03 mmol/L (softening stage) |
| Effluent Resistivity | Up to 10–18.2 MΩ·cm (deionization stage, configurable by grade) |
| Working Pressure | 0.2 – 0.6 MPa |
| Power Supply | 220V / 380V, 50/60Hz (customizable for local standards) |
| Filter Tank Material | FRP / Stainless Steel 304 / Stainless Steel 316 (optional) |
| Control Valve | Fully automatic multi-way valve (Runxin / Autotrol / Fleck optional) |
| Ion Exchange Resin | Food-grade / industrial-grade cation resin + mixed bed resin |
| Regeneration Mode | Automatic co-current / counter-current regeneration |
| Operating Temperature | 2℃ – 45℃ |
| Installation Type | Skid-mounted, pre-assembled before delivery |
Key Features & Advantages
Dual-stage Integrated Treatment: Combines water softening and deionization in one compact system, reduces water hardness and total dissolved solids (TDS) in a single pass for higher effluent quality.
Fully Automatic Operation: Equipped with an intelligent control valve, supporting automatic regeneration, backwash and reagent replenishment, greatly cutting manual operation and maintenance costs.
High-efficiency Ion Exchange: Adopts premium industrial-grade ion exchange resin, ensuring stable softening and deionization performance with a long service cycle.
Skid-mounted Compact Design: Pre-assembled on a skid for fast installation and commissioning, suitable for both new construction projects and existing water system upgrades.
Durable & Corrosion-resistant: Available with FRP or stainless steel filter tanks, stable performance under long-term continuous operation.
Working Principle
Softening Stage: Raw water flows through the cation exchange resin bed. Calcium and magnesium ions — the main causes of water hardness — are adsorbed by the resin, producing scale-free softened water.
Deionization Stage: Softened water further passes through the mixed-bed deionization unit (blended cation and anion exchange resin), removing most dissolved ions in the water to produce high-purity deionized water.
Application Scenarios
Boiler feed water treatment (prevents scaling and improves thermal efficiency)
Textile, printing and dyeing industry
Food and beverage production
Pharmaceutical and cosmetic manufacturing
Electronics and semiconductor processing
Chemical production and metal surface treatment
Commercial buildings, hotels and central water supply
Service & Customization
Pre-sales water quality analysis and solution customization to fit your actual working conditions
Full after-sales support including installation guidance, operator training and regular maintenance
Multiple optional configurations: different valve brands, tank materials, resin grades and remote monitoring modules
Our softening Machine are packaged in specially designed export wooden crates and shipped promptly after being loaded onto containers.
YUFENG water treatment equipment Co.,ltd was established in 2017 and located in "capital of logistcs" Linyi city,Shandong province.We are a dedicated team of professional specializing in manufacturing household and commercial water treatment plants.The products series are included reverse osmosis,ultra filtration,ultra pure water,water softening and related accessories or consumables. Meanwhile,we supply the serivce of OEM and customized according to the requirement. We guarantee the principle of honesty and timely delivery. Providing the most suitable solution for our customers is our ultimate goal.
Frequently Asked Questions (FAQ)
Q2: Can you customize the system capacity and configuration for our project?
A: Yes. We support full customization of treatment capacity from 0.5 m³/h to 80 m³/h, as well as tank material, valve brand, resin grade and remote monitoring functions. Simply tell us your raw water quality report and water demand, and we will tailor a suitable water purification solution for you.Q3: Is this system easy to install and operate?
A: The entire system is pre-assembled and tested on a skid before delivery. You only need to connect the inlet/outlet pipes and power supply on site. With the automatic control valve, the system runs 24/7 automatically including backwash, regeneration and water production, requiring almost no manual operation after commissioning.Q4: How often does the ion exchange resin need to be replaced?
A: Under normal operating conditions and regular maintenance, the softening resin has a service life of 3–5 years, and the mixed bed deionization resin lasts 2–3 years. Actual service life depends on raw water quality and daily operating hours. We will provide detailed maintenance guidelines after delivery.Q5: What chemicals are required for resin regeneration?
A: The softening cation resin is regenerated with saturated salt (NaCl) solution. The deionization mixed bed resin is regenerated with hydrochloric acid (HCl) and sodium hydroxide (NaOH) solution. We will specify the concentration and dosage in the operation manual.Q6: What after-sales support do you offer?
A: We provide 12 months warranty for core components, online installation guidance, operator training and lifetime technical consultation. We also supply original spare parts and replacement resins at competitive prices for long-term cooperation.
